Parameter

Details

Model

SS-20PTXG-CSUTL-M3(SM)

Make

SECURUS

Image Sensor

1/2.9“ Progressive Scan CMOS

Image Pixels

2304 x 1296 Pixels (3.0 MP)

Minimum Illumination

Color: 0.005Lux@F1.2; B/W: 0.001Lux@F1.2

Day/Night

Auto (ICR) / Color / Black & White

DWDR

Auto

BLC (Back Light Compensation)

On/Off

Night Vision

4Pcs Warm Light LED

2Pcs Strobe LED

Night Light Temperature

3000~3300K

Night Vision Technology

Colorsense® Technology

Night Distance

30 Meters

Lens Mount

2.8mm/3.6mm/4.0mm/6.0mm

Lens Type

Board Lens

Network Type

4G (Compatible with 5G Sim Card)

4G Standard

LTE-TDD/LTE-FDD/TD-SCDMA/ WCDMA

4G Frequency Band

LTE-FDD : B1/B3/B5/B8,

LTE-TDD : B34/B38/B39/B40/B41;

WCDMA:B1/B5/B8

Network Interface

10/100 MBPS RJ45 Connector

Network Protocol

HTTP, TCP, ARP, RTMP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPoE, IPv4/v6, SNMP, QoS, UPnP, NTP

ONVIF Protocol

Supported (Ethernet Port Only)

SD Card

Supported (Max: 512 GB)

Video Bitrate

128kbps ~ 8Mbps

Video Compression

H.265X, H.264

Video Streams

HD/SD, Rate Adaptation, Triple Stream

Image Resolution

Mainstream: 2304 x 1296, 1920*1080, 1280*720;

Auxiliary stream: 704*576, 640*480, 352*288

 Snapstream: 704*576, 640*480, 352*288

Frame Rate

1296P @ 15FPS; 1080P @ 15FPS;

720P @ 15FPS; D1 @ 15FPS

DNR

2DNR, 3DNR (Digital Noise Reduction)

Shutter Speed

1/25s ~ 1/100000s (Shutter Adaptation)

Digital Zoom

Supported (Max: 16X)

Audio Input

Yes; (Built-in Mic)

Audio Output

Yes; (Built-in Speaker)

Audio Compression

G.711A

Intelligent AI Feature

Human Detection, Sound Detection

Alarm Notification

Push Notification on Mobile Application

Image reversal

Vertical Flip / Horizontal Mirror

Privacy Mask

Up to 4 Areas

Antenna

Dual Antenna

Antenna Frequency Range

824-960MHz, 1710-2690MHz

Antenna Impedance

50Ω

Antenna VSWR

≤3.0

Antenna Gain

5dBi

Antenna Bandwidth

136/980MHz

Pan Range

0° ~ 355°

Pan Speed

0°/s ~ 20°/s

Tilt Range

-0° ~ +90°

Tilt Speed

0°/s ~ 10°/s

Housing Material

ABS

Weight

≤0.5 KGs

Dimension

156W X 138L X 279H

Operation Temperature

-10°C ~ +65°C

Operation Humidity

0% ~ 90%

Power Supply

DC12V

Power Consumption

≤5W

Ingress Protection

IP67

Mobile Application

PVMS Pro 4K

Mobile OS

Android, iOS

Browsers Supported

Chrome, Edge, Opera, Mozilla Firefox

Certifications

CE, FCC, RoHS
