Parameter

Details

Model

SS-MR04SH-TSHD-M1

Make

SECURUS

Operating System

Embedded Linux OS

Operating Interface

Graphic User Interface

Password Security

User Password / Admin Password

Video Standard

PAL / NTSC

Video Compression

H.264

Video Resolution

720P/960H/D1/CIF

Playback Resolution

720P/960H/D1/CIF

Recording Quality

1 ~ 6 Levels Optional

Image Display

1x1; 2x2

Audio Compression

G.726

Recording Mode

Video; Audio Video

Recording Mode

Manual / Alarm

Video Bitrate

Max : 4096 Kbps

Audio Bitrate

Max : 8 Kbps

Storage Media

SD Card + HDD/SSD Storage

Search Mode

Channel Type / Recording Type

Playback Mode

File Playback

Upgrade Mode

Manual/Automatic/Remote

Upgrade Method

USB Disk/ Wireless/ SD Card

AV Input

4Ch Aviation Interface

AV Output

VGA Output

Alarm Input

4 Input

HDD/SSD

1 x HDD/SSD (Max : 2TB)

Hot Swapping

Supported

SD Card

1 x SDXC High Speed Card

(Max : 256GB)

USB Interface

1 x USB 2.0

USB Supported

USB Hard Disk / USB Mouse

Ignition Input

1 x ACC Signal

UART

1 x LVTTL Interface

LED Indication

PWR / RUN

Disk Lock

1

Debug Port

1

GPS

Supported

3G/4G

Supported

3G/4G Signal Type

CDMA/ EVDO/GPRS/WCDMA/LTE

WIFI

Supported  (802.11b/g/n, 2.4 GHz)

Power Input

10V ~ 36V DC

Power Output

5V 300mA

Power Consumption

Max: 18 Watts ( Standby : 3mA)

Working Temperature

-20˚C ~ +70˚C

Storage Consumption

720P : 1 GB/Hour/Channel

Dimensions

162mm x 153mm x 52mm
