Parameter

Details

Model

SS-NE30XSP-M8(4K)

Make

SECURUS

Image Sensor

1/2.8” Progressive Scan CMOS

Image Pixels

3840 x 2160 (8.0 MP), 2880 x 1616 (5.0 MP), 2560 x 1440 (4.0 MP), 2304 x 1296 (3.0MP), 1920 x 1080 (2.0 MP)

Lens

4.3mm ~ 135mm (30x optical zoom)

Auto control IR LED

PWM

IR Distance

6Pcs IR LEDs+2Pcs Laser LEDs

Iris

Auto/Manual; F1.6 ~ F4.8

Shutter

Auto/Manual

Shutter Time

1/25s ~ 1/100000s

Minimum Illumination

Color: 0.005Lux@F1.2 B/W: 0.001Lux@F1.2

 (IR ON: 0.0 Lux)

S/N Ratio

≥ 50dB

Day/Night Mode

IR-Cut filter with auto switch (ICR)

IR Distance

150 Meters

Audio Compression

G.711, Support bidirectional talk, Audio & Video synchronization

Audio Input

Supports built-in Audio (Optional)

Video compression

H.265AI, H.265+, H.265, H.264

CVBS Output

Supports 1 x BNC Video Output(Optional)

Video Streams

Main Stream : 3840 x 2160; @15FPS; 2880 x 1616@25FPS; 2560 x 1440; @25FPS; 1920 x 1080; 25 FPS Sub Stream 1: 800 x 448; @25FPS

OSD

Up to 8 OSDs

Privacy Mask

Up to 8 Areas

Digital Zoom

16X

Alarm I/O

1/1 (Optional)

Intelligent AI Feature

People Counting, Customer Flow Statistics

Customer Flow Values

Enter, Leave & Pass Through (Max : 65,500 Per Day)

Statistics Reports

Daily, Weekly, Monthly & Annual Statistics

Reports Export

Export to Excel Sheet (.xls)

Network Protocols

HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPoE, IPv4/v6, SNMP, QoS, UPnP, NTP,FTP, DHCP

Software Control

IE, CMS, P2P(P6SLite)

Compliance

ONVIF

Pan Range

0°~360°

Pan Speed

0°/s ~ 240°/s

Tilt Range

-0° ~ +93°

Tilt Speed

0°/s ~ 240°/s

Auto Flip

Pan: 180°; Tilt: 93°

Presets

220/500 Presets

Dwell Time

1s ~ 60s Selectable

Guard Tours

3 Tours

Guard Points

Max: 16 Points

Communication Protocol

Pelco-D; Pelco-P

Baud Rate

9600BPS (Default)

A-B Scan

User programmable (Scan Speed 1-64 levels setting available)

BLC

Support

AGC

Auto/Manual

WB

Auto/Manual/Indoor/Outdoor

DNR

2DNR, 3DNR

WDR

DWDR

Park Time

1 ~ 60 Minutes

SD Card

Supported (Max: 512 GB) (Optional)

Network

10M/100M Base-TX Ethernet

Network Interface

1*RJ45 Connector 10/100 MBPS

Power Supply

12V 4Amp/POE(Optional,802.3at)

Power Consumption

~ 25W (Without IR)

Multiple Browsers

Supports (Chrome, Mozilla, Edge, Opera)

Mobile Monitoring

RMEye Pro (iOS & Android)

Housing Material

Aluminum + ABS

Weight

5.28 KGs

Working Temperature

-40°C ~ +60°C

Working Humidity

≤90% RH (Non Condensing)

Ingress Protection

IP67

Lightning Protection

Transient Voltage 6000V

Certifications

CE, FCC, ROHS, BIS
