Parameter

Details

Model

SS-N8032RV-H4-M5

Make

SECURUS

User Interface

Graphic User Interface (GUI)

Operating System

Embedded Linux

Operation Mode

Preview, Record, Playback, Backup, Network,

Smart Search

Playback Mode

Common Playback, Smart Search

Password Security

Multi-level User Management

ONVIF

Support

Video Input

32ch 5M/32ch1080P/8ch4K

HDMI Output

Supports (Max : 4K)

VGA Output

Supports (Max : 1080P)

CVBS main output

N.A.

Audio Input

1 Ch

Audio output

1 Ch, RCA connector

Display

1/4/6/8/9/10/13/16/25/32 optional

Video standard

PAL/NTSC

Video compression

H.265AI/H.265+/H.265/H.264+/H.264

Intelligent Functions

Face Detection, Vehicle Detection,

Human Detection, Active Deterrence,

Line Crossing, Trip Wire, People Counting

Video encoding resolution

12MP; 8MP; 5MP; 4MP; 3MP; 1080P

Network Protocol

HTTP, TCP/IP, UDP, DNS/DDNS, RTP, RTSP,

DHCP, NTP

Video frame rate

PAL: 1-25 FPS NTSC: 1-30FPS

Video bit rate

1536kbps-3072kbps

Stream Type

Video & Audio/Video

Audio compression

G.711a

Recording mode

Always/Schedule/Alarm Recording/Motion Detection Recording

Video search

Time/Channel/Event/Face Search/Vehicle Search

Display Zoom

Live Playback & Mobile

Audio bit rate

8—32kbps

Dual-stream

Supports

Mobile Monitoring

"RMEye Pro" Application for Android

And iPhone

Recording resolution

32 CH Realtime Recording

HDD Port

4 SATA

HDD Maximum Capacity

12TB for each Sata connector

Voice talk

Support; 1CH BNC line in/1CH RCA Audio out.

Record mode

Audio & Video recording simultaneously

Remote control

Supports

Network protocol

Supports IE/PPPoE/DDNS

Multiple IP Network Configuration

Supported

Network Bandwidth

240 Mbps Incoming / 240 Mbps Outgoing

  DDNS Server

www.securusddns.com

Network

1 RJ45 10M/100M/1000M

NVR to NVR Cascading

Remote, Local, Viewing, Recording

IPC firmware update

Supported

  USB Connector

2 x USB2.0, 1 x USB3.0

Firmware update

Support USB update/Network update

Serial Interface

RS485, RS232

Alarm input

16

Alarm output

4

Power supply

NVR: DC 12V 6A

Redundancy

Available

Network Security

Support Blacklist/Whitelist to prevent

unauthorized Network Access

Virtual Lan

Configure with Multi IP Addresses

Operation Temperature

-10℃ to＋65℃

Operation Humidity

10％ to 90％

Chassis

Standard 1.5U

Dimension

400.5mm (W) × 440mm (L) × 60mm (H)

Weight(without HDD)

≤1.0Kg

Certifications

CE, FCC, RoHS, BIS
