Parameter |
Details |
Model |
SS-20L2XG-CSUTL-M3(SM) |
Make |
SECURUS |
Image Sensor |
1/2.9“ Progressive Scan CMOS |
Image Pixels |
2304 x 1296 Pixels (3.0MP) |
Minimum Illumination |
Color: 0.005Lux@F1.2; B/W: 0.001Lux@F1.2 |
Day/Night |
Auto (ICR) / Color / Black & White |
DWDR |
Auto |
BLC (Back Light Compensation) |
On/Off |
Night Vision |
1Pcs Warm Light LED |
Night Light Temperature |
3000~3300K |
Night Vision Technology |
Colorsense® Technology |
Night Vision Distance |
20 Meters |
Lens Mount |
2.8mm/3.6mm/4.0mm/6.0mm |
Lens Type |
Board Lens |
Network Type |
4G (Compatible with 5G Sim Card) |
4G Standard |
LTE-TDD/LTE-FDD/TD-SCDMA/ WCDMA |
4G Frequency Band |
LTE-FDD : B1/B3/B5/B8, LTE-TDD : B34/B38/B39/B40/B41; WCDMA:B1/B5/B8 |
Network Interface |
10/100 MBPS RJ45 Connector |
Network Protocol |
HTTP, TCP, ARP, RTMP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPoE, IPv4/v6, SNMP, QoS, UPnP, NTP |
ONVIF Protocol |
Supported (Ethernet Port Only) |
SD Card |
Supported (Max: 512 GB) |
Video Bitrate |
128kbps ~ 8Mbps |
Video Compression |
H.265X, H.264 |
Video Streams |
HD/SD, Rate Adaptation, Triple Stream |
Image Resolution |
Mainstream: 2304*1296, 1920*1080; Auxiliary stream: 1280*720, 704*576, 640*480, 352*288 Snapstream: 704*576, 640*480, 352*288 |
Frame Rate |
1296P @ 15FPS; 1080P @ 15FPS; 720P @ 15FPS; D1 @ 15FPS |
DNR |
2DNR, 3DNR (Digital Noise Reduction) |
Shutter Speed |
1/25s ~ 1/100000s (Shutter Adaptation) |
Digital Zoom |
Supported (Max: 16X) |
Audio Input |
Yes; (Built-in Mic) |
Audio Output |
Yes; (Built-in Speaker) |
Audio Compression |
G.711A |
Intelligent AI Feature |
Human Detection, Sound Detection |
Alarm Notification |
Push Notification on Mobile Application |
Image reversal |
Vertical Flip / Horizontal Mirror |
Privacy Mask |
Up to 4 Areas |
Antenna |
Dual Antenna |
Antenna Frequency Range |
824-960MHz, 1710-2690MHz |
Antenna Impedance |
50Ω |
Antenna VSWR |
≤3.0 |
Antenna Gain |
3dBi |
Antenna Bandwidth |
136/980MHz |
Housing Material |
Aluminium + ABS |
Weight |
≤0.5 KGs |
Dimension |
80W X 143L X 128.5H |
Operation Temperature |
-10°C ~ +65°C |
Operation Humidity |
0% ~ 90% |
Power Supply |
DC12V |
Power Consumption |
≤5W |
Ingress Protection |
IP67 |
Mobile Application |
PVMS Pro 4K |
Mobile OS |
Android, iOS |
Browsers Supported |
Chrome, Edge, Opera, Mozilla Firefox |
Certifications |
CE, FCC, RoHS |
